UltraZOOM-1-DIGI Digital Stereo Microscope With Display Screen
Couldn't load pickup availability
GX Microscopes ultraZOOM-1-DIGI Routine Grade, Digital Trinocular Zoom Stereo Microscope Series
The ultraZOOM-1-DIGI is a routine grade, stereo zoom microscope with good optical quality, flat field objectives, widefield eyepieces, good quality output to camera, good zoom range – huge choice of stands. The build quality is high being all metal with optical grade glass optical components.
The ultraZOOM-1-DIGI has a magnification zoom range of: 7X-45X and is equipped with a camera port on the trinocular head as standard for live image viewing capture and analysis. Long working distance of 90mm without any additional auxiliary objectives.
- Amazing Value for Money
- This DIGI digital microscope is supplied with a 2MP microscope camera with a display screen for viewing the samples. Images and videos can be saved to a USB memory stick on the camera. This camera cannot connect to a PC
- Other stands are available- gooseneck stand, mirror base stand, tall pillar stand, boom arm stand, articulated arm stand. Please enquire about these options
- This is a versatile workhorse for almost any application.
- This microscope is one of the latest models by GX Microscopes. The ultraZOOM-1 has high quality optics which deliver a bright, crisp, high resolution image in beautiful 3D. The 3D effect is produced by the presence of a pair of angled zoom objectives each of which presents a slightly different view of the subject and transmits this to each eyepiece.
This microscope is suitable for use for almost every task including entomology, PCB repairs, research, university teaching, industrial inspection and any dissection work.
| Head | Trinocular- simultaneous output to eyepieces and camera port |
| Eyepieces | 10x FN22 |
| Eyepiece Tubes | 30mm internal diameter |
| Magnification range | 7x-45x (with 10x eyepieces and no extra objective) |
| Zoom Control | Pair of zoom knobs ergonomically located on both sides of the head with calibration marks for the magnification |
| Body | Fits 76mm microscope holder |
| Working Distance | 90mm (with no extra objective) |
| Stand | Large choice of stands including track, gooseneck, mirror base, boom arm, articulated arm |
| Camera | 2MP display camera |
| Auxillary Objectives | ||||
| Eyepieces | 0.5X (WD 165mm) | 0.75X (WD 105mm) | None (WD 90mm) | 2X (WD 30mm) |
| 10X | 3.5X-22.5X | 5.25X-33.75 | 7X-45X | 14X-90X |
| 20X | 7X-45X | 10.5X-67.5X | 14X-90X | 28X-180X |
| 25X | 8.75X-67.5X | 13.12X-84.38 | 17.5X-135X | 42X-225X |
| WD= Working Distance | ||||
