GX Microscopes ultraBIO-5 Fluorescence Microscope

GX Microscopes ultraBIO-5 Fluorescence Microscope

An excellent value fluorescence microscope for university teaching laboratories and routine use. This feature laden microscope has, as standard, auto power off, an enclosed safety stage and good quality optical and mechanical performance. This microscope is backed by a comprehensive life time warranty, as long as it is serviced annually by GT Vision's dedicated service team.

The ultraBIO-5 fluorescence microscope represents a new generation of affordable but advanced instruments with the latest optical design and advanced build quality incorporating all the features you would expect to find in much more expensive microscopes.

The fluorescence unit has four standard filter sets- UV (excitation 330-400nm, emission 425-700nm), Violet (excitation 395-415nm, emission 455-700nm), Blue (excitation 420-485nm, emission 515-700nm) and Green (excitation 460-550nm, emission 590-700nm). It is quick and easy to switch betwwen the filter sets, with the rotary selector. This fluorescence unit has long life LED illumination, so there are no costly bulbs to replace and no fiddly alignment issues.

The ultraBIO-5 fluorescence microscope features a widefield image (with 20mm FOV eyepieces), an ultra-modern design rackless stage, automatic power-off with activity detection, graduated Abbe condenser with Köhler illumination and an ergonomic and easy to carry stand with a variety of options as standard. Backed by a comprehensive technical and service support , the ultraBIO-5 fluoresence microscope sets a new standard for optical design, performance and affordability.

For our complete range of fluorescence microscopes see fluoresence microscopes

Head	Trinocular- 0:100, 100:0 eyepiece/ camera port with interpupiliary adjustment and diopter adjustment
Eyepieces	Pair 10X widefield eyepieces FN 20
Stand	Infinity optics
Nosepiece	Quintuple
Objectives	4x NA 0.10, 10x NA0.25, 40x Fluorite NA 0.85, 100x NA 1.25 oil
Stage	Double layer mechanical stage 152 x 132 mm
Focus Mechanism	Coaxial coarse and fine focus knobs
Condenser	Abbe condenser
Illumination	3W LED adjustable intensity. Auto-off eco mode function
Fluoresence	Built in UV, Violet, Blue and Green Fluoresence
