NexiusZoom EVO trinocular stereo microscope 6.5x-55x. Choice of stands- see below
Couldn't load pickup availability
NexiusZoom EVO stereo microscope trinocular head.
Pair wide field eyepieces HWF10x/23mm without eyecups
Trinocular head with 45° inclined tubes
Diopter adjustment ± 5° on two tubes. Interpupillary
distance adjustable between 54 and 75 mm
0.65x to 5.5x zoom objective, magnification from 6.5x to 55x with click stops
Field of view from 35 mm to 4.2 mm. Working distance 110 mm
For our complete range of stereo microscopes see- stereo microscopes
| Head | Trinocular |
| Eyepieces | 10x FN23 |
| Eyepiece Tubes | 30mm |
| Magnification range | 6.5x-55x |
| Zoom Control | Pair of zoom knobs ergonomically located on both sides of the head with calibration marks for the magnification |
| Body | Fits 76mm microsocpe holder |
| Working Distance | 110mm |
| Auxillary Objectives | ||||||
| Eyepieces | 0.3x (WD 287mm) | 0.5X (WD 188mm) | 0.75x (WD 105mm) | None (WD 110mm) | 1.5x (WD 53mm) | 2X (WD 40mm) |
| 10X | 2x-17x | 3.2x-27.5x | 4.9x-41.3x | 6.5x – 55x | 9.8x-82.5x | 13x-110x |
| 15X | 2.9x-24.8x | 4.8x-41.3x | 7.3x-61.9x | 9.8x-82.5 | 14.6x-123.8x | 19.5x-165x |
| 20X | 4x-34x | 6.5x – 55x | 9.8x-82.5x | 13x-110x | 19.6x-165x | 26-220x |
| WD= Working Distance | ||||||
